12V 277VAC 32A 40A 0.9W 25g 4pinminiature High Voltage Sugar Cube Power Relay
Shanghai, ChinaIvy Metering Co., Ltd.
US$0.59 - 1.15
MOQ5 pieces
Lead Time
| Quantity | 旺季 | 淡季 |
|---|---|---|
| 1 - 2000 | 15 days | 15 days |
| > 2000 | To be negotiated | To be negotiated |
Product profile
- Features
- sealed
- Connector Type
- standard
- Contact Material
- AgSnO2
- Pick-up & Release Time
- 15ms. typical/10ms. typical
- Use
- PCB
- Continuous Current
- 40A
- Termination Style
- standard
- Series
- standard
- Place of Origin
- Zhejiang, China
- Load Current
- standard
- Dielectric Strengh (contact to coil)
- 4000VAC
- Contact Distance
- 3mm or default
- Model Number
- IM-SP401A
- Size
- Miniature
- Coil Type
- standard
- Contact Rating (Current)
- standard
- Description
- Small High Capacity PCB Monostable Power Relay
- Output Type
- standard
- Brand Name
- IVY
- Switching Voltage
- Max. 277VAC
- Single package size
- 25X20X7 cm
- Voltage - Input
- standard
- Circuit
- standard
- Current - Input
- standard
- Coil Voltage
- 12VDC
- Voltage - Output
- standard
- Theory
- Electromagnetic Relay
- On-State Resistance (Max)
- standard
- Relay Type
- power relay
- Current - Output
- standard
- Application
- standard
- Single gross weight
- 0.081 kg
- Contact Form
- 1A
- Coil Current
- 75mA
- Mechanical Endurance
- 1*10^7 ops
- Voltage - Load
- standard
- Selling Units
- Single item
- Mounting Type
- PCB
- Type
- standard
