Chemins UV Online COD Sensor Analyzer Monitor Meter Probe Auto-Cleaning Wastewater Treatment RS485 4-20mA IP68 316L Stainless
Shandong, ChinaYantai Chemins Instrument Co., Ltd.
US$2050.00
Lead Time
| Quantity | 旺季 | 淡季 |
|---|---|---|
| 1 - 2 | 7 days | 7 days |
| > 2 | To be negotiated | To be negotiated |
Product profile
- Power consumption
- 0.4W (Measuring); 2W (Cleaning)
- Shell material
- 316L Stainless Steel
- Size / Dimension
- 32*185 mm
- Resolution
- 0.1 mg/L
- Function
- water quality detector
- Place of Origin
- Shandong, China
- Description
- Online COD Sensor (UV254 Method)
- Output method
- RS-485 (Modbus RTU); 4-20mA (Optional)
- Parameters
- COD, Turbidity, Temperature (BOD/TOC optional)
- Measuring Range
- 0~200 / 500 / 2000 / 4000 mg/L (Selectable)
- Brand Name
- Chemins
- Power - Max
- 12~24VDC
- Single package size
- 32.5X14X9.5 cm
- Measurement Range
- 0~200 / 500 / 2000 / 4000 mg/L (Selectable)
- Working conditions
- 0 ~ 45℃; Pressure ≤ 0.2 MPa
- Accuracy
- ±5% F.S.
- Voltage - Output (Typ) @ Distance
- 12~24VDC
- Usage
- water monitoring
- Output
- RS-485 (Modbus RTU); 4-20mA (Optional)
- Application
- waste water, STP, WWTP
- Protection grade
- IP68
- Single gross weight
- 1.000 kg
- Manufacturer Part Number
- COD-408
- Brand
- Chemins
- Output Function
- RS-485 (Modbus RTU); 4-20mA (Optional)
- Selling Units
- Single item
- Power supply
- 12~24VDC
- Mounting Type
- Immersion, NPT 3/4
