CNC Turn-Mill Center TCK56Y with A2-8 Spindle 10'' Hydraulic Hollow Chuck 12-Position BMT45 Live Turret ±45 mm Y-axis Travel
Beijing, ChinaBeijing JingOne Machine Tool Equipment Co., Ltd.
US$38000.00
Lead Time
| Quantity | 旺季 | 淡季 |
|---|---|---|
| 1 - 5 | 60 days | 60 days |
| > 5 | To be negotiated | To be negotiated |
Product profile
- weight
- 5700
- max. length of workpiece (mm)
- 1450
- brand name
- JingOne
- travel (z axis)(mm)
- 1500
- machinery test report
- Provided
- warranty
- 1 Year
- tool post stations
- 12
- dimension(l*w*h)
- 4000x2170x2200mm
- range of spindle speed
- 10 - 3000
- Turret type
- 12T BMT 45 live tool turret
- place of origin
- Beijing, China
- repeatability (x/y/z) (mm)
- ±0.008
- travel (x axis)(mm)
- 260
- Chuck
- 10 inch hydraulic chuck
- Axis motor torque (X/Z/Y)
- 22/22/6 N,m
- positioning accuracy (mm)
- ±0.01
- Single volume
- 0 cm³
- no. of spindles
- Single
- Max.turning diameter
- 440 mm
- Spindle nose type
- A2-8
- model number
- TCK56Y
- key selling points
- Multifunctional, High Productivity, Long Service Life
- Spindle bore diameter
- 86 mm
- Max.swing diameter over bed
- 640 mm
- number of axes
- 4
- max. weight of workpiece(kg)
- 500
- Guideway type
- Linear guide rail
- Single gross weight
- 0.0 kg
- video outgoing-inspection
- Provided
- type
- TURNING CENTER
- Y-axis travel
- ±45 mm
- cnc control system
- GSK
- Selling Units
- Single item
- Max.bar capacity
- 75 mm
- voltage
- 380 V
- machining capacity
- Heavy Duty
Company profile
Beijing JingOne Machine Tool Equipment Co., Ltd.
北京京一机床设备有限公司Beijing, ChinaRoom 86-896, Huoxing North Street, Huoxian Town Beijing China- CertifiedTrade Assurance
- Business Type: Trading Company
- Established: 2024
- Employees: 51 - 100 People
- Annual Export Value: US$10 Million - US$50 Million
- Avg. Response Time: ≤ 1h
- Certification: CE
Main Products
- Machine Tool Equipment
- CNC Machine Tools
Main Markets
Domestic Market(50.0%), North America(10.0%), Mid East(10.0%), South America(10.0%), Southeast Asia(5.0%), South Asia(5.0%), Eastern Europe(5.0%), Africa(5.0%)
